SIMPLY PRACTICAL
- Compact cargo bike that carries up to 50 kg on the rear rack, plus an additional 20 kg with optional front rack
- Create your ideal setup with different accessory options to carry your kid, your stuff, or even your dog
- Proven safe and reliable: frame and fork are EFBE-tested up to the 140 kg Maximum Gross Vehicle Weight
- Fits riders of different heights from 147 - 190 cm, weighing up to 120 kg (264 lb)
- Low standover height (49 cm) makes (dis)mounting and waiting at stops easier
- 1x8-speed Shimano Altus derailleur with trigger shifter
- Hydraulic disc brakes for great stopping power, even when carrying heavy loads
| SPEEDS |
1 x 8 |
| WEIGHT |
16.1 kg |
| GEAR INCHES |
2.45 - 7.57 m |
| FRAME SIZES |
One size |
| DISTANCE (SEATPOST TO HANDLEBAR) |
60 - 64 cm |
| DISTANCE (SADDLE TO PEDAL) |
62 - 110 cm |
| SUGGESTED RIDER HEIGHT |
147 - 190 cm |
| MAX GROSS VEHICLE WEIGHT |
140 kg |
| MAX RIDER WEIGHT |
120 kg |
| FRAME |
Tern Short Haul, Patented Design, 6061-AL, EFBE Tri-Test approved: 140 kg |
| FORK |
Steel, EFBE approved: 140 kg |
| STEM |
Forged, 31.8 |
| HEADSET |
TH, cartridge bearings |
| HANDLEBAR |
Low riser, 31.8, 6061-AL |
| GRIPS/BAR TAPE |
Velo ergonomic, lock-on |
| SADDLE |
Velo Comfort |
| SEATPOST |
31.6 mm, 6061-AL, micro-adjust clamp |
| SEATPOST CLAMP |
Tern Collar |
| FRONT BRAKE |
Hydraulic disc |
| REAR BRAKE |
Hydraulic disc |
| BRAKE LEVERS |
Hydraulic disc |
| BRAKE CABLE & HOUSING |
Hydraulic disc |
| FRONT HUB |
Disc, aluminum |
| REAR HUB |
8 spd, disc, aluminum |
| SPOKES AND NIPPLES |
Stainless steel |
| RIMS |
Doublewall, for disc |
| TIRES |
Schwalbe Big Apple, 55-406, puncture protection, Reflex |
| SHIFTER(S) |
1 x 8 spd, trigger |
| REAR DERAILLEUR |
Shimano Altus |
| CRANKSET |
Forged 6061-AL crankarm |
| CASSETTE/FREEWHEEL |
11-34T, 8 spd |
| BOTTOM BRACKET |
FSA, Cartridge, sealed bearings |
| CHAIN |
KMC, 8 spd |
| PEDALS |
Urban with non-slip surface |
| SHIFTER CABLE & HOUSING |
SP |
| BELL |
Aluminum |
| CHAINGUARD |
SKS Chainblade |
| KICKSTAND |
Pletscher design, rear mount |
| LUGGAGE SOCKET |
Combo Mount |
| FENDERS |
SplashGuard, stainless hardware |
| RACK(S) |
Atlas Q Rack, 6 point mounting, Vertical Parking, 50 kg capacity |
*Note: These are our standard model specifications. The bike's weight and folded dimension may not include racks and fenders. The specifications for your country may differ slightly. We do our best to ensure that the specifications listed here accurately reflect the exact parts found on our production bikes. However, component changes do occur for various reasons and there may be brief delays on site updates. We reserve the right to make component changes without prior notification, which may cause discrepancies with the information listed on the web.
